System settings
Use UTILITY mode (p. 42) to make various system settings for the PC-50.
fig.util*
1
Simultaneously hold the [MIDI CH] button and [PGM CHANGE]
button down.
The display will indicate “UTL,” and the PC-50 enters UTILITY
mode.
fig.sy0
2
Press the [SYSTEM] key.
The display will indicate “SY0” and blink.
fig.enter
3
Use the VALUE encoder or the [0] – [9] keys to specify the System setting that
you want to set, and then press the [ENTER] button.
* The setting will be cancelled if you press another button instead of the [ENTER]
button.
Confirm what’s indicated and use the appropriate method to make the setting.
Set the system settings
Display Mode
Key-
board
Content of the setting Default
Setting
method
F8 CLOCK
ON/OFF
0 Specify whether F8 Clock is to be transmitted. OFF p. 62
F8 CLOCK
DEFAULT
TEMPO
1
If “F8 CLOCK ON/OFF” is ON, specify the default value
of the F8 Clock. After the power is turned on, this tempo
will continue to be output until you move a controller to
which TEMPO is assigned.
120 p. 62
VELOCITY
CURVE
2
When you play the keyboard of the PC-50, note messages
will be transmitted with a velocity value that corresponds
to your playing strength. By setting the VELOCITY
CURVE, you can modify the keyboard’s sensitivity and the
curve that is followed when the velocity value changes.
1-MEDIUM p. 63
KEY
VELOCITY
3
Specify whether the transmitted velocity value will vary
according to the keyboard sensitivity and curve you select-
ed in “VELOCITY CURVE”, or will always be transmitted
at a fixed value.
TOUCH p. 64
MIDI I/F
MODE
4
Specify whether the PC-50 will function as a MIDI interface
using its MIDI connectors.
ON p. 65
VALUE
ENCODER
5
Select the parameter that is transmitted by the VALUE en-
coder.
VOLUME p. 66
FACTORY
RESET
6
Restore all settings of the PC-50 to their factory-set condi-
tion.
- p. 68
