Edimax Technology BR-6218Mg - Manual (Page 14)

Step 2) WAN Settings
In this section you have to select one of four types of connections that you will be using to connect your
broadband router’s WAN port to your ISP (see screen below).
Note: Different ISP’s require different methods of connecting to the Internet, please check with your ISP as
to the type of connection it requires.
Parameter Description
Dynamic IP Your ISP will automatically give you an IP address
Static IP Address Your ISP has given you an IP address already
PPPoE
Your ISP requires you to use a Point-to-Point Protocol over Ethernet (PPPoE)
connection.
PPTP
Your ISP requires you to use a Point-to-Point Tunneling Protocol (PPTP)
connection.
L2TP
Your ISP requires you to use a Layer Two Tunneling Protocol (L2TP)
connection.
Click on one of the WAN type and then proceed to the manual’s relevant sub-section (1.1, 1.2, 1.3, 1.4, 1.5
or 1.6). Click on Back to return to the previous screen.
13
