SUPREMA 2001 - OPERATION & SERVICE MANUAL
Page 48 of 60 July 6, 2001 Suprema 2001 - Operation & Service
REMOVING THE HEATER ELEMENT
1. Remove the water tank.
a) Refer to the " Removing the Water Tank " instructions in this manual.
2. Remove the lid assembly.
a) Refer to the " Removing the Water Tank Lid " instructions in this manual.
WARNING: To avoid severe burns, make absolutely certain that the heater element is
not hot before proceeding!
3. Remove the two 11/16" brass nuts securing the heater element to the lid.
4. Remove the heater element.
5. Detach the thermal cut-off probe from the heater element.
a) Remove plate/clamp securing the thermal cut-off probe to the element.
INSTALLING THE HEATER ELEMENT
1. Position the heater element into the tank lid.
a) The "curve" at the bottom of the heater element should point towards the
rear of the tank.
2. Secure the element to the tank lid with the two 11/16" brass nuts.
3. Replace thermal shut-off plate/clamp and probe.
4. Replace the lid assembly.
a) Refer to the "Installing the Water Tank Lid" instructions in this manual.
5. Replace the water tank.
a) Refer to the " Installing the Water Tank " instructions in this manual.
