©Elation Professional® 35 impression™
14. TECHNICAL SPECIFICATIONS
Power supply
Power consumption
350 VA (Watt)
Power Input 100-240 V AC, 50-60 Hz (wide range input)
Fuse protection Micro-fuse 5x20 mm, GMA 220v/4A
Operational Parameters
Max. Ambient
Temperature
45°C (integrated overheating switch)
Mounting Position Any (see chapter mounting)
Lighting System - Additive Color mixing
LED Type
90x Luxeon K2 High-power- LEDs
Lifetime 100.000 h
30 LEDs per color, wavelength optimized for maximum presentable color space
Optical System
High efficient Collimator cluster
Exchangeable optical carrier with 10° light distribution angle (25° optional)
Scattering light aperture
Shutter / Dimmer (8 Bit)
Strobe- Effect with variable speed between 1 - 10 flashes per second,
Random-Strobe, Pulse-Effects
Continuous Dimmer 0 - 100%
DMX Control
Standard USITT DMX-512,
3 pole XLR; [+] = Pin 3 [-] = Pin 2 [Ground] = Pin 1.
Die DMX- Addressing starts at the DMX channel [001].
Pan / Tilt (8/16 Bit)
Pan- movement
660° in min. 3.2 seconds (Position Feedback)
Tilt- movement 300° in min. 1.5 seconds (Position Feedback)
Weights and Measures
Width of the base
340 mm / 13.4”
Length of the base 145 mm / 5.7”
height (head vertical) 370 mm / 14.6”
Weight (net)
7.5 kg / 16.5 lbs
Please Note: Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice.
