©Elation Professional® 27 impression™

Channel

Function

Time and Value

DMX

HEX

%

Color 14 - Blue

Color temperature @
5600K

112..119 70..77 44..46.5

White – CTB

Color temperature @
7200K

120..127 78..7F 47..49.5

Rainbow Effect Stop

2)

128

80

50

Rainbow Effect

3)

Slow – fast

129-223 81..DF

51..88

Rainbow Effect, random colors

Slow - fast

224-255 E0..FF 89..100

6) Red

Color mixing system - Red

0 - 100%

0..255

00..FF

0..100

7) Green

Color mixing system - Green

0 - 100%

0..255

00..FF

0..100

8) Blue

Color mixing system - Blue

0 - 100%

0..255

00..FF

0..100

9) Shutter

Shutter closed

0..15

00..0F

0..5.5

Random Strobe (different pattern)

Slow - fast

16..47

10..2F

6..18.5

Dim-in then shutter closing (random
patterns)

Slow – fast

48..79

30..4F 19..31.5

Shutter open then dim-out

Slow – fast

80..111

50..6F

32..43

Dim-in then dim-out (random pattern) Slow – fast

112..143 70..8F

44..56

Strobe effect, slow – fast

0.2Hz – 10Hz

144.239 A0..EF

57..94

Shutter open

240..255 F0..FF 95..100

10) Dimmer

Dimmer

(0% - 100%)

0..255

0..FF

0..100

11) Color
temperature

No color correction

0

0

0

Continuous color temperature
correction between 7200k – 3200k

Applicable only when a
white color is selected

1..255

1..FF

1..100

12) Special

Max. Power-Mode (*)

Max. light output
without white balance

0..15

0..0F

0..5.5

White-Mode (*)

White balance used

16..31

10..1F

6..12.5

Color1-Chaser C / C+1
Slow – fast

0.7 BPS ... 2.3 BPS
=> 1.43 s ... 0.43 s

112..127 70..7F 44..49.5

Color1-Chaser C / C+2
Slow – fast

0.7 BPS ... 2.0 BPS
=> 1.43 s ... 0.5 s

128..143 80..8F 50..56.5

Fan min. as long as temp. < 60°C

224..229 E0..E5 88..89.5

RESET (Normal Mode)

250..255 FA..FF 98..100

13) Movement No movement

0

00

0

Moveme
nt

Size

Phase

PAN

1

01..01

01..01

0.5

1

90°

02..03

02..03

1.0

1

180°

04..05

04..05

1.7

1

270°

06..07

06..07

2.5

PAN

2

08..09

08..09

3.3

2

90°

10..11

0A..0B

4.1

2

180°

12..13

0C..0D

4.9

2

270°

14..15

0E..0F

5.7

PAN

3

16..17

11..11

6.5

3

90°

18..19

12..13

7.3

3

180°

20..21

14..15

8.0

3

270°

22..23

16..17

8.8

PAN

4

24..25

18..19

9.6

4

90°

26..27

1A..1B

10.4

4

180°

28..29

1C..1D

11.2

4

270°

30..31

1E..1F

12

TILT

size / phase see also PAN

32..63

20..3F

13..25
