©Elation Professional® 29 impression™
Compressed Mode - 10 DMX Channels
Channel
Function
Time and Value
DMX
HEX
%
1) Pan Coarse 0.. 660°
Min. 3.2 s
0..255
00..FF
0..100
2) Pan Fine
High- Pos ... High- Pos + 2.6° (16 Bit)
0..255
00..FF
0..100
3) Tilt Coarse 0.. 300°
Min. 1.5 s
0..255
00..FF
0..100
4) Tilt Fine
High- Pos … High- Pos + 1.2° (16 Bit)
0..255
00..FF
0..100
5) Color Wheel Colors adjustable via RGB
0..7
00..07
0..2.5
(Fixed)
Color 01 – Red
1)
8..15
08..0F
3..5.5
Color 02 – Amber
1)
16..23
10..17
6..8.5
Color 03 – Warm Yellow
1)
24..31
18..1F
9..12.5
Color 04 – Yellow
1)
32..39
20..27 13..15.5
Color 05 – Green
1)
40..47
28..2F 16..18.5
Color 06 – Turquoise
1)
48..55
30..37 19..21.5
Color 07 – Cyan
1)
56..63
38..3F 22..24.5
Color 08 – Blue
1)
64..71
40..47 25..27.5
Color 09 – Lavender
1)
72..79
48..4F 28..30.5
Color 10 – Mauve
1)
80..87
50..57 31..34.5
Color 11 – Magenta
1)
88..95
58..5F 35..37.5
Color 12 – Pink
1)
96..103
60..67 38..40.5
White – CTO
Color temperature
@ 3200K
104..111
68..6F 41..43.5
Color 14 - Blue
Color temperature
@ 5600K
112..119
70..77 44..46.5
White – CTB
Color temperature
@ 7200K
120..127
78..7F 47..49.5
Rainbow Effect Stop
2)
128
80
50
Rainbow Effect
3)
Slow – fast
129-223
81..DF
51..88
Rainbow Effect, random colors
Slow - fast
224-255
E0..FF
89..100
6) Red
Color mixing system - Red
0 - 100%
0..255
00..FF
0..100
7) Green
Color mixing system - Green
0 - 100%
0..255
00..FF
0..100
8) Blue
Color mixing system - Blue
0 - 100%
0..255
00..FF
0..100
9) Shutter
Shutter closed
0..15
00..0F
0..5.5
Random Strobe (different pattern)
Slow - fast
16..47
10..2F
6..18.5
Dim-in then shutter closing (random
patterns)
Slow – fast
48..79
30..4F 19..31.5
Shutter open then dim-out
Slow – fast
80..111
50..6F
32..43
Dim-in then dim-out (random pattern)
Slow – fast
112..143
70..8F
44..56
Strobe effect, slow – fast
0.2Hz – 10Hz
144.239
A0..EF
57..94
Shutter open
240..249 F0..F9 95..97.5
RESET
Min. 3 Sec.
250
FA
98
Shutter open
251..255 FB..FF 99..100
10) Dimmer
Dimmer (0% - 100%)
0..255
0..FF
0..100
