Press the Set button to display the main menu.
Position the cursor at BACK LIGHT and press the left or
right button to setting the back light on.
Press the left or right button again, back light setting
returns to off.
1
2
3
Press the Set button to display the BLC zone set.
Press the up, down direction buttons to move the cursor
to desired BLC zone.
Press the left, right direction buttons to setting the
sensing zone which want to preserve visibility in
important section of the scene. After setting, press the
Set button to return to main menu.
1
2
3
Back Light Compensation
Press the Set button to display the main menu on the
monitor screen.
Position the cursor at TEXT DISPLAY and press the left or
right button to set the text display on.
Press the left or right button again, text display setting
returns to off.
1
2
3
Text Display
Press the Set button to text generation when position
the cursor at TEXT DISPLAY and text display mode is on.
Press the left, right, up, down direction buttons for
selecting characters. Text is generated when you press
the Set button over the selected character.
A maximum of 24 alphanumeric characters (1 line) can be
displayed on the screen.
1
2
Text Generation
Press the Set button for setting text location when
position the cursor at POS in the Text generation menu.
Press the left, right, up, down direction buttons to move
the text location.After setting, press the Set button to
return to main menu.
1
2
Text Location
P. 770.270.1394 F. 770.270.2389 865 Marathon Parkway Lawrenceville GA 30046
7
Backlight control use 6 sensing zones. The BLC zone setting is
activated on the screen by left or right button to allow the
most suitable area to be selected while observing the monitor.
Press the Set button to select BLC zone when position the
cursor at BACK LIGHT and back light mode is on.
Decide a BLC zone number for desired portions of the scene.
*Position the cursor at Zone display and press the set button to
view zone.
BLC Zone setting
Strong light, such as from a spotlight or window, entering the
scene background causes the lens iris to close, thereby
possibly obscuring desired portions of the scene. Back light
compensation functions automatically adjusts the video level
so as to preserve visibility important sections of the scene.
*Zone Display
Zone 1 OFF
Zone 2 OFF
Zone 3 OFF
Zone 4 OFF
Zone 5 OFF
Zone 6 OFF
Zone 1
OFF
Zone 2
OFF
Zone 3
OFF
Zone 4
OFF
Zone 5
OFF
Zone 6
OFF
Zone 5
OFF
BLC ZONE SET
TEXT GENERATION
A B C D E F G H I J K L M N O P Q R S
T U V W X Y Z a b c d e f g h i j k l
m n o p q r s t u v w x y z 1 2 3 4 5
6 7 8 9 0 . , ‘ : + - ~ / * # ( ) < >
BLK
CLR POS END
Camera 1
to Locate, then SET
