Unpacking and Setup
Unpacking
LW Scientific packs each Mi5 Microscope with utmost care. Examine the outer
and inner containers for any visual damage. Retain all of the packing material
until you have examined and tested your new microscope. If there is
damage, please contact the shipping company, as our warranty does not
cover shipping damage. If you are uncertain who the shipper is, contact the
distributor where you purchased the microscope. Please retain all packaging material for future use. Carefully unpack
your Mi5 Microscope using the following checklist for all the parts and accessories:
Remove all 3 small boxes from the large box and set on a firm work area.
Open Box # 3 and take out microscope base. Set on table/bench. Carefully remove all Styrofoam, zip ties from
stage (if applicable), and tissue paper and finally, any applicable stickers from stage. Next, pull out the (4) objectives
and the (2) eyepieces from the top Styrofoam container--set them on the table (these will be used in the microscope
assembly steps).
Open Box # 1 labeled: Binoc/Trinoc Head. Open the box and carefully open plastic bag with the microscope head
in it and set it aside. Next, remove the eyepiece caps and tissue from the bottom of the binoc/trinoc head.
Open Box #2 labeled: Analyzer Module and Accessories. Carefully remove items from foam/bubble wrap packaging
and set the analyzer module next to the microscope base and binoc/trinoc head. You should now have the basic 3
components to assemble your microscope.
Box 1: Head of microscope
Box 2: All accessories for scopes
Box 3: Base of microscope & objectives
