©Elation Professional® 29 impression™

High Resolution Mode - 13 DMX Channels

Channel

Function

Time and Value

DMX

HEX

%

1) Pan Course 0 .. 660°

min. 3,2 s

0..255

00..FF 0..100

2) Pan Fine

High- Pos ... High- Pos + 2,6° (16 Bit)

0..255

00..FF 0..100

3) Tilt Course 0 .. 300°

min. 1,5 s

0..255

00..FF 0..100

4) Tilt Fine

High- Pos … High- Pos + 1,2° (16 Bit)

0..255

00..FF 0..100

5) Red Coarse Color Mix – Red

0 - 100%

0..255

00..FF 0..100

6) Red Fine

Color Mix – Red - High

0 - 100%

0..255

00..FF 0..100

7) Green
Coarse

Color Mix – Green

0 - 100%

0..255

00..FF 0..100

8) Green Fine Color Mix – Green - High

0 - 100%

0..255

00..FF 0..100

9) Blue Coarse Color Mix – Blue

0 - 100%

0..255

00..FF 0..100

10) Blue Fine Color Mix – Blue - High

0 - 100%

0..255

00..FF 0..100

11) Shutter

Shutter Closed

0..15

00..0F

0..5,5

Random Strobe (different pattern)

16..47

10..2F 6..18,5

Pulse effect, slow - fast

48..79

30..4F 19..31,

5

Strobe, slow - fast

1 Hz .. 10 Hz

80..239 50..EF 32..94,

5

Shutter Open

240...24

9

F0..F9 95..97,

5

RESET

Min. 3 Sec.

250

FA

98

Shutter Open

251..25

5

FB..FF 99..100

12) Dimmer
Course

Dimmer (0% - 100%)

0..255

0..FF

0..100

13) Dimmer
Fine

Dimmer -High

0..255

0..FF

0..100
