Compressed Mode - 10 DMX Channels
Channel
Function
Time and Value
DMX
HEX
%
1) Pan Coarse 0 .. 660°
Min. 3,2 s
0..255
00..FF
0..100
2) Pan Fine
High- Pos ... High- Pos + 2,6° (16 Bit)
0..255
00..FF
0..100
3) Tilt Coarse 0 .. 300°
Min. 1,5 s
0..255
00..FF
0..100
4) Tilt Fine
High- Pos … High- Pos + 1,2° (16 Bit)
0..255
00..FF
0..100
5) Color Wheel Colors adjustable via RGB
0..7
00..07
0..2,5
(Fixed)
Color 01 - Cyan
8..15
08..0F
3..5,5
Color 02 - Magenta
16..23
10..17
6..8,5
Color 03 - Yellow
24..31
18..1F
9..12,5
Color 04 - Lavender
32..39
20..27 13..15,5
Color 05 - Dark Lavender
40..47
28..2F 16..18,5
Color 06 - Amber
48..55
30..37 19..21,5
Color 07 - Deep Golden
56..63
38..3F 22..24,5
Color 08 - Dark Blue
64..71
40..47 25..27,5
Color 09 - Pink
72..79
48..4F 28..30,5
Color 10 - Lime Green
80..87
50..57 31..34,5
Color 11 - Light Blue
88..95
58..5F 35..37,5
Color 12 - Red
96..103
60..67 38..40,5
Color 13 - Green
104..111 68..6F 41..43,5
Color 14 - Blue
112..119 70..77 44..46,5
White
120..127 78..7F 47..49,5
Rainbow Effect
slow - fast
128..255 80..FF 50..100
6) Red
Color mixing system - Red
0 - 100%
0..255
00..FF
0..100
7) Green
Color mixing system - Green
0 - 100%
0..255
00..FF
0..100
8) Blue
Color mixing system - Blue
0 - 100%
0..255
00..FF
0..100
9) Shutter
Shutter closed
0..15
00..0F
0..5,5
Random Strobe (different pattern)
16..47
10..2F
6..18,5
Pulse effect , slow - fast
48..79
30..4F 19..31,5
Strobe, slow - fast
1 Hz.. 10 Hz
80..239 50..EF 32..94,5
Shutter open
240...249 F0..F9 95..97,5
RESET
Min. 3 Sec.
250
FA
98
Shutter open
251..255 FB..FF 99..100
10) Dimmer
Dimmer (0% - 100%)
0..255
0..FF
0..100
