Jordan Valve Mark 508 Series – Tank Blanketing Valve User Manual

Page 15

background image

TABLE 6 TANK BLANKETING VALVE CAPACITIES 1” MARK 608BP WITH 1/4” ORIFICE

Range

Setpoint

Inlet Pressure

330Nitrogen @ 0.97sg

Deviation from Setpoint (in/water)

+/- 0.5

+/- 1.0

+/- 2.0

2 - 5.5" w.c.

2" w.c.

5

71

389

495

20

751

1220

1220

40

2356

2356

2356

60

3029

3167

3167

80

4186

4186

4341

100

5460

5460

5460

125

6590

6779

6779

150

7759

7979

7979

2 - 5.5" w.c.

4" w.c.

5

212

441

530

20

516

1126

1501

40

1296

2298

2356

60

3167

3029

3098

80

4108

4186

4186

100

3412

5119

5119

125

6025

6025

6025

150

7099

7099

7099

4 - 10" w.c.

7" w.c.

5

247

354

495

20

352

845

1408

40

471

1650

2415

60

757

3167

3167

80

1240

4031

4263

100

5119

5119

5289

125

6214

6214

6214

150

7319

7319

7319

5 - 30" w.c.

20" w.c.

5

53

141

247

20

164

258

422

40

236

530

943

60

275

551

1239

80

388

620

1860

100

512

1024

2047

125

753

1506

2260

150

881

1761

2642

0.5 - 1.75 psi

1 psi

5

141

212

530

20

282

1314

1408

40

471

1060

2239

60

551

1239

3167

80

775

1550

2636

100

1194

2218

4777

125

1318

2260

6025

150

1541

2642

7099

1 - 3.5 psi

3 psi

5

318

707

707

20

657

1501

1501

40

1296

2239

2356

60

2891

3029

3167

80

3876

4186

4341

100

4777

5119

5289

125

5649

5837

6026

150

6659

6879

7099

-12-
