Jordan Valve Mark 508 Series – Tank Blanketing Valve - Manual (Page 14)

TABLE 6 TANK BLANKETING VALVE CAPACITIES 3/4” MARK 608BP WITH 3/8” ORIFICE
Range Setpoint Inlet Pressure
330Nitrogen @ 0.97sg
Deviation from Setpoint (in/water)
+/- 0.5 +/- 1.0 +/- 2.0
2 - 5.5" w.c. 4" w.c.
5 424 601 1202
20 375 1220 2158
40 1414 3299 4359
60 826 4406 6471
80 6046 8062 8372
100 8701 10237 10237
4 - 10" w.c. 7" w.c.
5 212 424 990
20 938 1408 2346
40 236 1296 3535
5 - 30" w.c. 20" w.c.
5 106 177 354
20 188 282 610
40 236 471 1296
60 138 344 1239
80 310 775 1783
100 682 1365 3242
125 565 1224 1695
150 661 1431 1981
0.5 - 1.75 psi 1 psi
5 141 283 813
20 375 704 2065
40 530 1178 3181
60 620 1515 4544
80 698 1783 5891
100 768 2218 7337
125 1036 2448 8285
150 1210 2862 9740
1 - 3.5 psi 3 psi
5 495 849 1131
20 892 1971 3003
40 1767 3417 4595
60 2203 4681 6747
80 2248 5581 7907
100 2986 4948 10578
125 3766 8097 11863
150 4458 9520 13978
