PP.P5G5.02Troubleshoot

Page 13

Rev. 06/11/2003

Power Supply Check (24V)

Step 6 (For GPD 506/P5 models)

Measure the isolated 24V power supply on the control board at
terminals S1 ~ S6 using terminal SC (Gnd) as a common point.

DC

Volt

Meter

-

+

24V

S1 S2 S3

S4 S5 S6

SC SC

FS FC

ETC61502X-SXXXX

GPD 506/P5
