HEIDENHAIN TNC 640 261
8.8 A
d
ditional F
unctions
8.8 Additional Functions
Overview
Press the DIVERSE FUNCTION soft key to call the additional
functions. The TNC then displays the following soft keys:
Function Soft key Page
FN 14:ERROR
Output of error messages Page 262
FN 16:F-PRINT
Formatted output of texts or
Q-parameter values Page 267
FN 18:SYS-DATUM READ
Read system data Page 271
FN 19:PLC
Send values to the PLC Page 280
FN 20:WAIT FOR
Synchronize NC and PLC Page 280
FN 29:PLC
Transfer up to eight values to the PLC Page 282
FN 37:EXPORT
Export local Q parameters or
QS parameters into a calling program Page 283
