109

ND 500

4

USB (type B)

500 mA max.

Data I/O

1

2

3

4

+5 V

Data (-)

Data (+)

GND

5

X1, X2, X3 - « TTL

7

6

2

3

4

5

8

9

1

U

P

0 V

U

a1

¢

U

a2

£

U

a0

¤

/

Connector pin assignments
