Computer In connector pin assignments
■ ■ ■ ■ ■ ■
71
Computer In connector pin
assignments
The Computer In connectors are female video RGB, 15-pin
micro-D-style connector. The pin assignments are:
Input pin Signal
1 Red analogue input
2 Green analogue input
3 Blue analogue input
4 GND
5 GND
6 Red GND
7 Green GND
8 Blue GND
9 Reserved
10 Sync GND
11 GND
12 SDA
13 Horizontal sync/composite sync input
14 Vertical sync input
15 SCL
