Triton Plus - SD/3G-HD/HD -User Manual
33
Specifications
Timing
• SD, PAL: within clock intervals (27MHz) 565–835 Line 6
• SD, NTSC: within clock intervals (27MHz) 565–835 Line 10
• HD Tri-level: 1280x720: within clock intervals (148.5MHz) 455–780 Line 7
• HD Tri-level: 1920x1080: with clock intervals (148.5Mhz) 625–1070 Line 7
Power Supply
TPS-PWR-40
40W power supply unit for 8x8 to 32x32
TPS-PWR-90
90W power supply unit for 64x64 versions
AC supply voltage range
100-240VAC, 50-60Hz max 1.6A (TPS-PWR-40)/max 3A (TPS-PWR-90)
AC mains connector
IEC 320
DC output
• +15V, max. 2.2A/-15V, max 1.35A. Maximum 43W for 8x8–32x32 versions;
• +15V, max. 4A/-15V, max 2.5A. Maximum 90W for 64x64 versions
DC connector
DB9, female
Status monitoring
Via LED in front of router/CP
Control
Standard Features
Serial port
RS-232 for protocol conversion, to Triton Plus compact control protocol, or to
3rd party protocols
Connector
DB9, female
NCB ports
For integration with Triton Plus compact router configuration
Connectors (2)
RJ45 (1 in/1 out)
Ethernet
10/100BaseT Ethernet is not supported at this time
Connector
RJ45
Synchronization
• Analog Black Burst, Looped; Both PAL and NTSC supported
• Tri-level, Looped; For HD signal formats only
• Distribution of synchronization signals between several routers
Connector(s)
BNC
Optional Features
Control panel
• Optional, built-in control panel available
• External control panels available
Environmental
Equipment will meet guaranteed performance specifications under the following conditions:
Operating room temperature range
0º C to 45º C
Operating relative humidity range
< 95% (non-condensing)
Equipment will operate without damage under the following conditions:
Temperature range
-10º C to 55º C
Relative humidity range
< 95% (non-condensing)
Mechanical
Dimensions
• HxWxD = 44x483x50mm (19 in., 1 RU)
• HxWxD = 88x483x50mm (19 in., 2 RU)
• HxWxD = 176x483x50mm (19 in., 4 RU)
Safety/Emission standards
Compliant with CE EN55103-1 and 2
Table 34. Triton Plus SD/3G-HD/HD Video Specifications
Parameter
Value
