24 Triton Plus - SD/3G-HD/HD -User Manual
LED Status Indication
LED Status Indication
Start Up
The LED located at the front of the router indicates the status of the router.
At start-up, the LED will alternate between red (R) and green (G) every
500ms for about two seconds. After the start-up sequence the LED will
indicate the Alarm state of the router.
Alarm States
The LED can either be red (R), green (G), or have no light (N).
The LED state is described in Table 30 below with twenty letters, each rep-
resenting 100ms, which totals an alarm sequence of two seconds. The X
indicates that the LED keeps the color it has the moment the alarm
sequence begins (green or no light).
Table 30. LED Alarm States
Description LED State Alarm Comment
Continuous Green Light GGGGG GGGGG GGGGG GGGGG
No Alarm
Status OK
Long Red Blinking RRRRR NNNNN RRRRR NNNNN Power is too low
One Short Red Blink RXXXX XXXXX XXXXX XXXXX Power A failed
Only active if power
alarm DIP is set.
Two Short Red Blinks XXXXX XXXXX RXRXX XXXXX Power B failed
