Control Panel Operation
Control Panel Operation
Note This chapter is only applicable for routers with the optional local control
panel.
All local control panels are given a default configuration, which includes
the buttons
A/V Toggle , Panel Enable , Take On/Off , and Take . In addition, Input and
Output buttons are pre-configured.
Button Description
A/V Toggle
The A/V Toggle button enables/disables audio and video on a specified
address. The address can either be read from the DIP switches or be fixed.
The button toggles between three states.
Note If the button is pressed for more than 1 second, it will go into a fourth state
where both audio and video are disabled.
In this state the button will be dimmed. If the button is pressed for more
than 1 second again, it will enable both audio and video if present. Refer to
Table 33 .
If neither audio nor video is present, it will be marked as disabled and the
toggle state will not be used.
Toggle status changes will be stored in flash and used when the panel is
powered up later.
Table 33. A/V Toggle Button
Button Color Video Enabled Audio Enabled
Yellow Yes Yes
Green Yes No
Red No Yes
Dimmed No No
