Installation
Chapter 3 provides a functional description of the NV9648.
Topics
Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Installing Software and Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Initialization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Package Contents
If you have ordered one or more NV9648 control panels from Grass Valley, inspect the shipping
container for damage. If you find any container damage, unpack and inspect the contents. If the
contents are damaged, notify the carrier immediately.
As you unpack the shipping container, look for the packing slip and compare it against the
contents to verify that you received everything as ordered. If anything is missing (or if you find
equipment damage unrelated to shipping), please contact technical support. Refer to
Grass
Valley Technical Support on page 101 .
Depending on your order, the NV9648 items that can ship include:
• One or more NV9648 control panels.
• One or two power supplies for each NV9648, with straps that secure the AC power cords to
the power supplies.
• One or more rack-mounting kits (NV9649-48-RMK).
• Optional WC0053 breakout cable.
The package does not contain network cables, serial cables, or mounting screws. (The rack-
mounting kit, if present, does contain screws.)
You do not need to take any special precautions regarding ESD.
This document does address the relationship of the NV9648 to the NV9649. Otherwise, this
document does not address the shipment or installation of any other equipment or software
that can be used in conjunction with the NV9648 (including the NV9000 system controller,
NV915 system controller, other NV96xx control panels, EC9700 GUI, EC9710 GUI, and configura-
tion programs such as UniConfig or NV9000-SE Utilities).
This document does briefly address the use of NV9000-SE Utilities and the Panel IP Configura-
tion Utility as they pertain to panel configuration.
