4 bmo box connectors, 1 triax connector – Grass Valley MOBox Mixed-Operation Systems User Manual
Page 22
Mixed Operation User’s Guide | LDK 4901 BMO box
14
3.4
BMO box connectors
Figure 16. BMO Box connector location
3.4.1
Triax connector
Figure 17. Triax connector
HD SDI
Connect to camera
100 - 240V 50-60 Hz
MAINS T1A
CLASS 1 LASER PRODUCT
Connect to
Base Station
230
Mains power
inlet
Fiber
connector
Triax
connector
HD-SDI
output
2
1
3
1.
Inner pin (signals + power)
2.
Inner shield (return)
3.
Outer shield (housing)
panel view
