Mixed Operation User’s Guide | LDK 4900 CMO adapter 8
2.4 CMO adapter connectors
Figure 7. LDK 4900 CMO adapter connector location
2.4.1 Fiber connector
Figure 8. Fiber connector (LEMO)
Eng
Prog
r
Prod
Call
Mic
VF
Front Rear 48V
Ext
Script
Light
Breaker
Power on
DC in
CVBS (option)
Eng
Off
Prod
Ext
Mix
Front
Rear
Loc
TP
Mic 2
48V On
12V 1.5A DC Out
Ext 2
Ext 1
fiber connector
DC Power supply input
Mini Triax connector
HD-SDI video input
1
2
3
4
5
1. Power
2. Fiber A
3. Return
4. Fiber B
5. Shield
Shield of cable directly to the connector housing.
NOTE: actual fiber connector type depending on the CMO
adapter version.
SMPTE 304M compliant type LEMO EDW.3K.93C; panel view
