Page 46
K2 Edge Installation and Service Manual - document version: 4.0.2 – Page 46
20 Appendix: GPIO and LTC pinning
LTC - DB9M
LTC_out
+ (positive) pin 2
LTC_out
- (negative) pin 4
LTC_out GND
GND ground) pin 1
LTC_in
+ (positive) pin 7
LTC_in
- (negative) pin 8
LTC_in GND
GND (ground) pin 9
GPIO is an open collector port.
GPIO - DB9M
GPI0 pin 1
GPI1 pin 2
GPI2 pin 3
GPI3 pin 4
GPI4 pin 5
GPI5 pin 6
GPI6 pin 7
GPI7 pin 8
GND pin 9
