K2 Edge Installation and Service Manual - document version: 4.0.2 – Page 32
14 Appendix: The IP Manager Quick Reference
The IP Manager enables remote server management, monitoring and configuration. The IP Manager
is accessible via web, or via the LCD-panel on the front of the server. Two menus are available:
• the K2 Edge-menu: standard menu
• the IP Manager menu: also available when the system is unreachable (note that this menu
has less options)
If the system is unreachable, press the knob for 3 seconds to switch from the K2 Edge menu to the IP
Manager menu.
14.1 Starting the IP Manager web interface
To access the IP Manager, enter the IP Manager's IP-address in a web browser.
14.2 The LCD front panel
Use the rotary knob to operate the IP Manager via the front panel:
• Turn the rotary knob backwards and forwards to scroll through
options.
• Press the rotary knob to select an item or confirm a selection.
• Selected items are marked by [], <>, an arrow, or are highlighted.
• Press the knob 3 seconds to return to the main menu.
• Or, to discard changes and return to the main menu from a sub menu,
rotate the knob to the
• back/cancel/discard option, then press the knob.
In the IP manager, to save the changes you made, select Set/OK.
Changes in Channel settings have to be activated after being set: select Set/OK, then Activate/The
changed settings to activate changes. Note that when changes are activated, the nexos processes
are restarted which will interrupt playout.
If activation is required, the Activate/The changed settings option is available. When working via the
front panel, you have to scroll to this option.
Changing settings and executing commands via the IP Manager can interrupt a broadcast.
