K2 Edge Installation and Service Manual - document version: 4.0.2 – Page 36
• UDP Monitoring: use this option to monitor Channel 0 (the single HD or SD Channel, or the HD
Channel in a simulcast setup) via IP. When enabled, a MPEG- transport stream with encoded
video, graphics, subtitles and audio (first stereo track) is sent over Ethernet using the UDP-
protocol. A video player such as VLC is installed on a workstation to view output.
The UDP-monitoring option is described in more detail in the K2 Edge User Manual.
• Resolution: 320x240/ 240x180/ 160x120
• Aspect Ratio: 4:3/ 16:9
• Video Bitrate: in kbit/s
• Audio Enabled: On/Off
• Audio Bitrate: in kbit/s
• Ethernet Output: select On to enable monitoring and start streaming, Off to disable.
• IP-address: IP-address of the target workstation (can be a multicast address)
• IP-port: port the player will listen to. Default 4000
14.6 System administration
• Server start/stop
• Reboot
• shutdown
• Forced power off: only use when a shutdown is not possible.
• Forced reset: only use when a Reboot is not possible.
• Manage services
Services are:
• database
• dataserver
• encoderd
• firebird
• nexos
• playout_distri
• pt_guard
• schedulesync0
• sequencer0
Options for each service are:
• View the service’s version and status.
• Start the service.
• Stop the service.
• Restart the service.
Services are described in more detail in the Engineering manual.
