8 2090MDC Instruction Manual
2090MDC HDTV Monitoring Downconverter
Figure 6. Monitor Output Mode Examples
Complete picture which can zoom
from letterbox to full screen with
horizontal shift adjustment at any
zoom level greater than minimum
letterbox
Complete picture in
Letterbox format with
blanking at top and bottom
Complete picture with vertical
distortion (objects appear taller),
no blanking at top or bottom
Complete picture with no distortion;
can be shifted left or right
= Horizontal shift
= Horizontal shift
Letterbox – Mode 1
Amorphous – Mode 2
Full Screen – Mode 3
Zoom – Mode 4
Shift to right
Shift to right
Shift to left
Shift to left
Zoom
Zoom Zoom
Zoom
