Model NGA 2000 TO2
h. Temperature Measurement
Used to set the temperature display units.
Figure 3-23. Temperature Measurement
Set the upper and lower alarm limits for sample
flow as desired.
The actual flow rate displays below the line.
TO2 37.50 ppm
-- Analyzer Module Setup and Controls --
Calibration…
Alarms…
Ranges…
Linearization…
Measurement display configuration…
Concentration measurement…
Flow measurement…
Temperature measurement…
Measure Back… Status…
TO2 37.50 ppm
Measure Back…
-- Temperature Measurement --
Temperature measurement units: °C
Sensor temperature current: 789 uA
Sensor temperature: 35.7 °C
Main Menu
↓
Analyzer and I/O, expert controls and setup…
