Elation Professional Design Spot 300 PRO - Manual (Page 9)

Design Spot 300 Pro™
©Elation Professional, Los Angeles Ca. 9 www.ElationLighting.com
3. FEATURES
• Pan 540° or 630˚ (User selectable) / Tilt 265°
• 3 operation mode: DMX controlled, stand alone or sound activated
• 8 user replaceable colors plus white (including UV filter)
• User selectable color change (mode 1: full colors, mode 2: split-colors)
• CMY Variable Color Mixing
• Two Gobos Wheels:
o Rotating gobo wheel with 6 rotating gobos plus open, all gobos can be easily
replaceable and gobo indexing
o Static gobo wheel with 7 static gobos plus open with different speed gobo
shaking and gobo indexing
• Strobe effect: 0~18 flashes per second or random strobe
• Prism and prism rotation, with 16 prism macros
• Frost Filter for Soft and Hard Edge Spot
• Bright Phillips MSR Gold 300/2 Fast Fit Lamp (300w / 8000K / 750Hrs / 22,000Lm)
• Dimmer intensity from 0%~100%
• Electronic Power Supply (120v/60Hz)
• Control board with full LCD character display and foil-keyboard
• Reversible Display Option (180˚ Flip)
• RDMX (Remote DMX addressing from any DMX console)
• Auto test for all functions
• Automatic Pan/Tilt Correction
• Built-in Iris (5% ~ 100%), with Iris Pulse Effect
• Glass Dichroic Reflector for Even Lamp Output
• Anti-Reflective Coated Lenses
• USITT DMX-512 Complaint (3-pin and 5-pin DMX Connections)
• Electronic Zoom (16˚ ~ 41˚)
• Electronic Focus via DMX
• Pan and Tilt Locking System
• 8 User Assignable Program Presets - Internal Program: Edit and save programs to
the incorporated EEPROM. Maximum of 64 scenes.
