Design Spot 300 Pro™
©Elation Professional, Los Angeles Ca. 50 www.ElationLighting.com
defective motor IC drive on the main PCB).
Color-wheel error:
The color wheel is not located in the default position after start-up or after a reset command.
This message will appear after a fixture reset if the color wheel’s magnetic-indexing circuit
malfunctions (sensor failed or magnet is missing) or there is a stepper motor failure
(defective motor or a defective motor IC drive on the main PCB).
Cyan Color error:
(Cyan Color-wheel error) This message will appear after the reset of the fixture if the
magnetic-indexing circuit malfunctions (sensor failed or magnet missing) or the
stepping-motor is defective (or its drive circuit on the main PCB). The Cyan Color wheel is
not located in the default position after the reset.
Magenta Color error:
(Magenta Color-wheel error) This message will appear after the reset of the fixture if the
magnetic-indexing circuit malfunctions (sensor failed or magnet missing) or the
stepping-motor is defective (or its drive circuit on the main PCB). The Magenta Color-wheel
is not located in the default position after the reset.
Yellow Color error:
(Yellow Color-wheel error) This message will appear after the reset of the fixture and if the
magnetic-indexing circuit malfunctions (sensor failed or magnet missing) or the
stepping-motor is defective (or its driver circuit on the main PCB). The Yellow Color -wheel is
not located in the default position after the reset.
Rotating gobo-wheel error:
The gobo-wheel is not located in the default position after start-up or after a reset command.
This message will appear after a fixture reset if the gobo wheel’s magnetic-indexing circuit
malfunctions (sensor failed or magnet is missing) or there is a stepper motor failure
(defective motor or a defective motor IC drive on the main PCB).
