Design Spot 300 Pro™
©Elation Professional, Los Angeles Ca. 61 www.ElationLighting.com
24 (16bit – default) or 22 (8bit – user selectable)
Drive
Standard DMX-512, 3 pole XLR; [+] = Pin 3 [-] = Pin 2 [Ground] = Pin 1 or 5 pole XLR; n/a = Pin
5, n/a = Pin 4, [+] = Pin 3, [-] = Pin 2, [Ground] = Pin 1
Starting DMX [001].
Pan / Tilt
Pan - movement
630° in max. 2.0 seconds, 16 bit resolution
Tilt - movement 265° in max. 1.5 seconds, 16 bit resolution
Weights and Measures
Width of the base
18” / 46cm (Including Handles)
Length of the base 13.75” / 35cm (Without Handles)
Width of Head 18.5” / 47cm
Height (head vertical) 25” / 63.5cm
Weight (net) 26.3Kgs / 58Lbs
Operating Noise Levels (Base level 46.8dB)
Mode: Auto
1m = 55.9 dB
Mode: High 1m = 56.2 dB
Mode: Auto 1m = 51.6 db (Lamp off)
