Design Spot 300 Pro™
©Elation Professional, Los Angeles Ca. 32 www.ElationLighting.com
8.6.3 Calibrate values – This function should only be performed by a qualified technician.
This function allows a user to make small adjustments to the effect wheels (color,
gobo, shutter, etc) to compensate for ware or in the event a sensor has been knocked
slightly out of place. Because improper use of this function can result in undesired
operation this function has been password protected. The password is 050 and must
be entered each time the calibration menu function is entered. Because calibration is
an extremely delicate procedure instruction on performing this action are left out of
this manual. For a first time calibrator, please contact our customer support team for
step-by-step instructions.
8.7 User Mode Set:
8.7.1 User mode – This function allows the user to create user defined channel orders
allowing the fixture to match the channel order of other fixtures on the market for
easier operation. A total of three user modes may be configured: User Mode A, User
Mode B, and User Mode C.
8.7.2 Edit User mode – This function allows the user to make the actual changes in the
user-defined modes that are created in the previous function.
8.8 EDIT PROGRAM: - The fixture comes equipped with a built-in DMX recorder that allows
custom programs to be installed and recalled directly from the fixture’s control board.
Programs can be created and stored using the fixture’s control board or by using an
external DMX controller. For detailed instructions on how to complete this task please
see Section 11/ Page 37.
8.8.1 Select program – This function allows the user to select one of ten of the user
defined built-in programs. This program is then accessed in “Function Mode” under
“Program Run.”
8.8.2 Edit program – This function allows the user to edit the built-in programs.
8.8.3 Edit Scenes – This function allows the user to edit or define the actual scenes that
are stored in the user defined built-in programs that are accessed in the previous
