LEGEND:
NS=NOT SHOWN
WHEN ORDERING,SPECIFY THE
COLOR WANTED ON PARTS
CONTAINING THE LETTER "P"
NO. QTY. PART NO. DESCRIPTION
1
1 100085P SECTION 7
2
2 100178
UHMW 3/4 X 1" SQ WEAR BLK
3
2 100179P 1" WEAR BLK CVR
4
2 046025
1/4-20 X 1 1/2 HEX BOLT
5
2 044023
1/4-20 NYLOCK NUT
NO. QTY. PART NO. DESCRIPTION
1
1 100080P SECTION 6
2
2 100178
UHMW 3/4 X 1" SQ WEAR BLK
3
2 100179P 1" WEAR BLK CVR
4
2 046025
1/4-20 X 1 1/2 HEX BOLT
5
6 044023
1/4-20 NYLOCK NUT
6
2 100088
CORNER FRICTION BLOCK
7
2 100089P CORNER BLOCK COVER
8
4 043060
3/8 INT STAR WASHER
9
4 046020
1/4-20 X 1 1/4 GR5 HEX BOLT
10
4 047005
1/4 FLAT WASHER
11
1 100160
2 1/2 PULLEY
12
1 100642
5/8 X 1 SHOULDER BOLT
13
1 044048
NUT NYLOCK 1/2-13 HEX PL
14
2 100062
3/8 UHMW SPACER
15
4 041023
#10 X 3/8 PLS
16
2 100071
3/16 CABLE BOLT
17
2 044096
1/2-20 HEX NUT PL
NO. QTY. PART NO. DESCRIPTION
1
1 100075P SECTION 5
2
2 100094
UHMW 1 1/2 WEAR BLK
3
2 100095P 1 1/2 WEAR BLOCK COVER
4
2 046025
1/4-20 X 1 1/2 HEX BOLT
5
6 044023
1/4-20 NYLOCK NUT
6
2 100088
CORNER FRICTION BLOCK
7
2 100089P CORNER BLOCK COVER
8
4 043060
3/8 INT STAR WASHER
9
4 046020
1/4-20 X 1 1/4 GR5 HEX BOLT
10
4 047005
1/4 FLAT WASHER
11
1 100160
2 1/2 PULLEY
12
1 100642
5/8 X 1 SHOULDER BOLT
13
1 044048
NUT NYLOCK 1/2-13 HEX PL
14
2 100062
3/8 UHMW SPACER
15
4 041023
#10 X 3/8 PLS
16
2 100071
3/16 CABLE BOLT
17
2 044096
1/2-20 HEX NUT PL
SECTION 5
SECTION 6
MLEX
V SERIES
SECTION 7
2/2/2010
PG 4D
