LEGEND:
NS=NOT SHOWN
WHEN ORDERING,SPECIFY THE
COLOR WANTED ON PARTS
CONTAINING THE LETTER "P"
6
3
2
5
4 1
NO. QTY. PART NO. DESCRIPTION
1 8 044023 1/4-20 NYLOCK NUT
2 4 330014 SNAP RING
3 4 330010 LONG JACK
4 8 041050 1/4-20 X 3/4 TRUSS BOLT
5 4 650722 SPRING PIN L/R
6 4 100841P OUTRIGGER
MLEX V SERIES
PG 8A
OUTRIGGERS & JACKS
3/16/2010
