08
INSTALLATION & CONNECTION
Installing / Removing the Belt Clip
Installing the Belt Clip:
1. Put the belt clip on the back of the unit, and the screw clockwise
until it stops.
2. Confirm that the belt clip is securely attached.
* Tighten up the screw occasionally.
Removing the Belt Clip:
Turn the screw counter-clockwise to remove the belt clip.
Caution: Use the screws of specified size only. Others may cause
damage to the product. (screws size PM Φ 2.5mm x 3mm)
Accessories
Open the jack cover and insert the accessory
plug into the jack, as shown.
When the accessory is not used, please be sure
to put on cover with securely.
