Technical Data
32 3A1185H
Technical Data
LP400/500/600/700, Mustang 5100/8100
US Metric
Power requirements 120V AC, 60 hz, 11A, 1 phase
230V AC, 50/60 hz, 7.5A, 1 phase
Generator required 3000 w minimum
Maximum working pressure 3000 psi 21 MPa, 207 bar
Maximum delivery
LP400 0.46 gpm 1.75 lpm
LP500 0.54 gpm 2.0 lpm
LP600 (International) 0.66 gpm 2.5 lpm
LP700 0.74 gpm 2.8 lpm
LP600 (North America) 0.85 gpm 3.2 lpm
Maximum tip size
LP400 0.021
LP500 0.023
LP600 (International) 0.025
LP700 0.027
LP600 (North America) 0.027
Fluid outlet npsm 1/4 inch
Noise (dBa)
Sound pressure 80 dBa
Wetted parts zinc and nickel-plated carbon steel, nylon, stainless
steel, PTFE, acetal, leather, UHMWPE, aluminum,
tungsten carbide
Notes
Sound pressure measure at 3.1 feet (1 meter) from equipment.
