Electrical system – AIRLESSCO LP500 User Manual
Page 30
Parts
30
3A1185H
Electrical System
ON/OFF
Switch
Power Plug
from Motor
Black (+)
White
Black
Green
2 x Red
Black (-)
Black
Black
ti2471b
1
3
5
6
7
120V
230V
3
1
7
5
6
from Motor
Green/Yellow
Black/Brown
White/Blue
Power
Plug
2 x Red
Black
Black/White
ON/OFF
switch
ti22758a
Ref. Part
Description
Qty
Ref. Part
Description
Qty
1
POWER CORD
1
3
301083 TOGGLE SWITCH
1
331163 (120V)
1
5
PRESSURE CONTROL ASSEMBLY
1
867427 (230V)
1
6
243222 KIT, REPAIR TRANSDUCER
1
301101 (240V)
1
7
256219 POTENTIOMETER
1
118046 (110V)
1
8 15T069 LABEL,WARNING (120V)
1
15H087 LABEL,WARNING (230V)
Additional warning labels are available at no cost.
