Using the Document Camera
5. Turn the lighting units toward the lighting arms until they stop;
then tilt the lighting arms toward the stage (inward).
6. Rotate the lighting units backward, as shown, until they stop.
caution
Be careful not to let the
camera arm drop, or you may
damage it.
stage
lighting unit
lighting arm
lighting unit
lighting arm
