Connecting the rca cable, Setting up the document camera, Video out – Epson ELPD04 User Manual
Page 17
12
Setting Up the Document Camera
Connecting the RCA Cable
Before you start, make sure your document camera and projector or
TV are turned off.
1. Connect one end of the RCA cable to the document camera’s
VIDEO OUT
port.
2. Connect the other end of the RCA cable to the RCA input port
on the projector or TV.
AC IN
RGB IN
RGB OUT
ON
OFF
RS-232C
POWER
VIDEO
OUT
USB
0
1
A B C
or
projector
TV
video out
elpdc04.book Page 12 Tuesday, February 12, 2002 8:32 AM
