Setting Up the Document Camera 9
Unfolding the Document Camera
Follow these steps to unfold the document camera:
1. Raise the camera arm until you hear a click, then lower it slightly
until it locks into place.
2. Rotate the camera head so that the lens faces the stage
(downward).
3. Raise the right lighting arm, as shown, until it stops.
lighting arm
camera head
stage
