FW-1804
Applications Guide
7733 Telegraph Rd • Montebello, CA • 90640 • phone 323.726.0303 • www.tascam.com
© 2004 TEAC Corporation All trademarks are the property of their respective holders. All rights reserved. Design and specifi cations
subject to change without notice. Product photographs are shown only to illustrate the types of product which are compatible with
the TASCAM FW-1804. These products are not manufactured by the TASCAM Division of TEAC Corporation.
FW-1804 Connections
˘
(4) Balanced XLR / W" TRS Mic / Line
inputs
˘
(4) W" TRS Analog Inserts (Channels 1 - 4)
˘
(4) W" TRS Line Inputs
˘ (2) W" TRS Control Room Outputs
˘ W
" TRS Headphone Output
˘ RCA S/PDIF Digital Input and Output
˘
Toslink ADAT Digital Input and Output
˘
BNC Word Clock Input and Output
˘
(2) MIDI Inputs
˘ (4) MIDI Outputs
˘
(2) FireWire connectors (In/Thru)
˘ W
" Footswitch Input
˘
(2) IEEE-1394 FireWire jacks
FW-1804 Bundled Free Software
The following free software is included with
the FW-1804:
˘
Cubase LE
õ
48 audio tracks and 64 MIDI tracks
õ
96kHz / 24-bit resolution
õ
Supports VST FX and instruments
õ
Sophisticated MIDI track editing
õ
Loop slice, stretch, groove and
tempo analysis
õ
Upgrade path to Cubase SX
˘
GigaStudio 3 LE
õ
64-voice polyphony
õ
16-channel multitimbral MIDI
õ
ReWire and VST plug-in support
õ
Includes MegaPiano piano library
õ
Compatible with all GigaStudio libraries
˘
Nomad Factory Demo Version
õ
Blue Tubes Bundle, Rock Amp Legends and
Liquid Bundle plug-in demo install
õ
One free delay plug-in permanent install
