Page 14
DS_S36SE05003_07312008
14
PART NUMBERING SYSTEM
S 36 S E
050
03
N
R
F
A
Product
Type
Input
Voltage
Number of
Outputs
Product
Series
Output
Voltage
Output
Current
ON/OFF Logic
Pin
Length/Type
Option
Code
S - Small
Power
18V~75V
S - Single 1x1,
17W
050 - 5.0V
03 - 3A
N - Negative
(Default)
P - Positive
E - No remote
on/off control
R - 0.170”
(Default)
N - 0.145”
K - 0.110”
M - SMD
F- RoHS 6/6
(Lead Free)
A - No trim pin
B - With trim pin
(Default)
MODEL LIST
MODEL NAME
INPUT
OUTPUT
EFF @ 100% LOAD
S36SE3R305NRFB 18V~75V 1.3A
3.3V
5A
86.5%
S36SE05003NRFB 18V~75V 1.1A
5.0V
3A
83.5%
S36SE12001NRFB 18V~75V 1.1A
12V
1.3A
87.0%
Note:
1. Default remote on/off logic is negative;
2. Default pin length is 0.170”;
3. Default OTP and output OVP, OCP mode is auto-restart
4. For different options, please refer to part numbering system above or contact your local sales office.
CONTACT
:
www.delta.com.tw/dcdc
USA:
Telephone:
East Coast: (888) 335 8201
West Coast: (888) 335 8208
Fax: (978) 656 3964
Email:
Europe:
Phone: +41 31 998 53 11
Fax: +41 31 998 53 53
Email:
Asia & the rest of world:
Telephone: +886 3 4526107 ext 6220
Fax: +886 3 4513485
Email:
WARRANTY
Delta offers a two (2) year limited warranty. Complete warranty information is listed on our web site or is available upon
request from Delta.
Information furnished by Delta is believed to be accurate and reliable. However, no responsibility is assumed by Delta
for its use, nor for any infringements of patents or other rights of third parties, which may result from its use. No license
is granted by implication or otherwise under any patent or patent rights of Delta. Delta reserves the right to revise these
specifications at any time, without notice
.
