Delta Electronics Delphi S36SE - Manual

DATASHEET
DS_S36SE05003_07312008
FEATURES
Š High efficiency: 83.5% @5V/3A
Š Industry standard 1x1 pinout
Š Size: 27.9x24.4x8.7mm (1.10”x0.96”x0.34”)
Š Fixed frequency operation
Š 4:1 ultra wide input voltage range
Š Input UVLO
Š Output OCP, OVP and OTP
Š Monotonic startup into normal and pre-bias
loads
Š Output voltage trim ±10%
Š 2250V isolation and basic insulation
Š No minimum load required
Š SMT and Through-hole versions
Š ISO 9001, TL 9000, ISO 14001, QS9000,
OHSAS18001 certified manufacturing facility
Š UL/cUL 60950-1 (US & Canada)
Recognized, and TUV (EN60950-1)
certified.
Š CE mark meets 73/23/EEC and 93/68/EEC
directives
APPLICATIONS
Š Optical Transport
Š Data Networking
Š Communications, including Wireless
and traditional Telecom
Š Servers
OPTIONS
Š Positive, negative, or no On/Off
Š OTP and Output OVP, OCP mode,
Auto-restart (default) or latch-up
Š Surface mounted pins
Delphi S36SE, 17W 1x1 Brick Series
DC/DC Power Modules: 18~75V in, 5V/3A out
The Delphi S36SE series, 1x1 sized, 18~75Vin, single output,
isolated DC/DC converters are the latest offering from a world leader
in power systems technology and manufacturing  Delta Electronics,
Inc. This product family is available in either a surface mount or
through-hole package and provides up to 17 watts of power or 5A of
output current (3.3V and below) in a standard 1x1 form factor
(1.10”x0.96”x0.33”). The pinout is compatible with the popular
industry standard 1x2 sized products. With creative design
technology and optimization of component placement, these
converters possess outstanding electrical and thermal performance,
as well as extremely high reliability under highly stressful operating
conditions. The S36SE 5V module could provide full output power
without any airflow up to 77
°C ambient temperature while keeping the
component junction temperatures under most derating guidelines. All
modules are fully protected from abnormal input/output voltage,
current, and temperature conditions.
