7.0) DIMENSIONS
Top V
iew
Bottom V
iew
18”
161-5/16”
exhaust outlet
perforated panel
tube exchanger
Side V
iew
36”
109-1/2”
15-13/16”
suspension bracket
suspension bracket
suspension bracket
32”
(out
side bracket
s)
9-1/2”
End V
iew
rivet
s
