39
Par
ts
LARGE HYDRAULIC FILTER PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 23-190 Elbow 45° 3 /
4
NPT 2
2 18-074 Bushing, 1 1 /
4
- 3 /
4
2
3 33-171 Oil Filter Bracket 1
4 60-215 Oil Filter Assembly 1
5 18-140 Fitting 1
6 60-334 Oil Filter Element 1
SMALL HYDRAULIC FILTER PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 23-031 Oil Filter Element 1
2 23-190 45° Elbow 2
3 HNTL-38-16 Lock Nut, 3 /
8
- 16 2
4 13-217 Oil Filter Bracket 1
5 HB-14-20-075 Bolt 1 /
4
- 20 x 3 /
4
2
HW-14 Washer 1 /
4
2
HWL-14 Lockwasher 1 /
4
2
6 HB-38-16-100 Bolt 3 /
8
- 16 x 1 2
HW-38 Washer 3 /
8
2
7 23-006 Small Oil Filter Assembly 1
