71
Accessories
13-116 SAND CULTIVATOR PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 HCP-12-150 Clevis Pin 1 /
2
x 1 1 /
2
2
2 13-121 Right Frame Cultivator 1
3 34-016 Floorboard Support 1
4 13-146 Attachment Lift
HSSQ-38-16-200 Square Head Set Screw 3 /
8
-16 x 2 1
HN-38-16 Nut 3 /
8
- 16 1
HB-38-16-125 Bolt 3 /
8
- 16 x 1 1 /
4
1
HW-38 Washer 3 /
8
1
HNTL-38-16 Lock Nut 3 /
8
- 16 1
5 HMB-12-14 Machine Bushing 1 /
2
x 14GA 1
6 HP-18-100 Cotter Pin 1 /
8
x 1 1
7 HMB-34-10 Machine Bushing 3 /
4
x 10GA 12
8 HRP-14-100 Roll Pin 1 /
4
x 1 2
9 HN-38-16 Nut 3 /
8
- 16 8
10 HWL-38 Lockwasher 3 /
8
8
11 13-120 Left Frame Cultivator 1
12 13-096 Blade 4
13 HB-38-16-125 Bolt 3 /
8
- 16 x 1 1 /
4
8
14 13-115 Hitch (Pistols) 2
15 HHP-18 Bridge Pin 1 /
8
2
INSTALLATION INSTRUCTIONS
1. Attach cultivator frames (Ref 11 and 2) together at center pin using machine bushings (Ref 5) and cotter
pin (Ref 6).
2. Bolt four blade assemblies (Ref 12) to frames using eight bolts (Ref 13), lockwashers (Ref 10) and nuts
(Ref 9). The blade points should angle down and forward.
3. Insert hitch, (pistols) (Ref 14) into tubes of frames (Ref 11 and 2) with up to five bushings (Ref 7) in front
and one bushing in the rear of tube. Secure pistols with roll pins (Ref 8). Check spacing before driving
roll pin in all the way. For more tire clearance, the machine bushing may be moved from front to rear.
4. Slide pockets of cultivator frames over arms of attachment lift (Ref 4).
5. Hook pistols up to tabs under trap rake frame by using rear holes with clevis pins (Ref 1) and bridge pin
(Ref 15).
6. Start engine to test operation of cultivator. Raise and lower attachment checking for leaks and to see
whether they are fairly level.
