21
Diagrams
HYDRAULIC PARTS LIST
(KOHLER AIR COOLED )
REF # PART # DESCRIPTION QUANTITY
1 13-032 Wheel Motor 1
2 13-424 Hydraulic Hose 1
3 13-425 Hydraulic Hose 1
4 13-409 On-Off Valve 1
5 34-174 Hydraulic Hose 2
6 34-140 Hydraulic Hose 2
7 13-584 Oil Tank 1
23-095 Filler Breather 1
8 34-171 Hydraulic Hose 1
9 34-102 Wheel Motor 2
10 34-170 Hydraulic Hose 1
11 8832-32 Hose 3 /
4
1
18-222 Hose Clamp 2
12 42-003 Hydrostatic Pump 1
13 23-006 Oil Filter 1
23-031 Replacement Filter Only
14 8917-18 Suction Hose 5 /
8
1
15 34-131 Hydraulic Hose 1
16 34-132 Hydraulic Hose 1
17 75-714 Cylinder (steering) 1
18 34-130 Hydraulic Hose 2
19 34-103 Orbitrol Motor 1
20 34-133 Hydraulic Hose 1
21 13-357 Hydraulic Cylinder 1
22 13-292 Hydraulic Cylinder 1
23 34-172 Hydraulic Tube (short) 2
24 34-173 Hydraulic Tube (long) 2
25 34-144 Hydraulic Hose 2
26 34-136 Hydraulic Hose 2
27 42-220 Hydraulic Valve (2-Bank) 1
42-232 Supreme Handle Kit (2-Bank) 1
28 34-142 Hydraulic Hose 1
29 34-105 Oil Cooler 1
30 18-190 Swivel Tee 2
31 34-057 Tee 2
32 34-058 Swivel Tee 2
HYDRAULIC PRESSURES
Pump Displacement
.913 in. 3 / rev
Pump Input Speed (up to) 3600 rpm
Max. Operating Pressure 3500 psi, 4500 Peek psi
Charge Pump Displacement .33 in. 3 / rev
Max. Inlet Vacuum 5 in. Hg
Max. Case Pressure 25 psi
Relief Valve Pressure (set at) 3600 psi
13-261 Hydraulic Valve (2 bank) 700 psi
