Hydraulic parts list – Smithco Supreme 35-000-A (sn 101988) Parts & Service Manual User Manual
Page 21
19
Diagrams
HYDRAULIC PARTS LIST
(KAWASAKI LIQUID COOLED)
REF #
PART #
DESCRIPTION
QUANTITY
1
13-032
Wheel Motor
1
2
13-424
Hydraulic Hose
1
3
13-425
Hydraulic Hose
1
4
13-409
On-Off Valve
1
5
34-174
Hydraulic Hose
2
6
34-140
Hydraulic Hose
2
7
13-584
Oil Tank
1
23-095
Filler Breather
1
8
34-171
Hydraulic Hose
1
9
34-102
Wheel Motor
2
10
34-170
Hydraulic Hose
1
11
8832-6
Hose
1
18-222
Hose Clamp
2
12
34-109
Hydrostatic Pump
1
13
23-006
Oil Filter
1
23-031
Replacement Filter Only
14
8832-13
Suction Hose
1
18-222
Hose Clamp
2
15
34-131
Hydraulic Hose
1
16
34-132
Hydraulic Hose
1
17
75-714
Cylinder
(steering)
1
18
34-130
Hydraulic Hose
2
19
34-103
Orbitrol Motor
1
20
34-133
Hydraulic Hose
1
21
13-357
Hydraulic Cylinder
1
22
13-292
Hydraulic Cylinder
1
23
34-172
Hydraulic Tube
(short)
2
24
34-173
Hydraulic Tube
(long)
2
25
34-144
Hydraulic Hose
2
26
34-136
Hydraulic Hose
2
27
42-220
2- Bank Hydraulic Valve
1
42-232
Supreme Handle Kit
(2-Bank)
1
28
34-142
Hydraulic Hose
1
29
34-105
Oil Cooler
1
30
18-190
Tee
1
31
34-057
Tee
2
32
34-058
Swivel Tee
2
33
17-018
Tee, Male Branch
1
HYDRAULIC PRESSURES
Pump Displacement
.913 in.
3
/ rev
Pump Input Speed
(up to)
3600 rpm
Max. Operating Pressure
3500 psi, 4500 Peek psi
Charge Pump Displacement
.33 in.
3
/ rev
Max. Inlet Vacuum
5 in. Hg
Max. Case Pressure
25 psi
Implement Setting
700 - 1000 psi
13-261 Hydraulic Valve
(2 bank)
900 psi
