39
Parts
GAS TANK PARTS LIST
(KAWASAKI LIQUID COOLED)
REF# PART# DESCRIPTION QUANTITY
1 13-588 Replacement Cap for 13-585 Gas Tank 1
2 13-585 Gas Tank with Cap 1
3 26-054 Bushing Insert 1
4 8800-10 1 /
4
" Fuel Hose 1
5 50-403 Inline Gas Filter 1
6 18-186 1 /
4
" Hose Clamp 3
7 26-055 Shut-Off Valve 1
8 HB-14-20-075 Bolt 1 /
4
- 20 x 3 /
4
4
HW-14 Washer 1 /
4
4
HWL-14 Lockwasher 1 /
4
4
9 34-036 Gas Tank Bracket 1
HYDRAULIC OIL TANK PARTS LIST
(KAWASAKI LIQUID COOLED)
REF# PART# DESCRIPTION QUANTITY
1 17-019 Male Elbow 1
2 17-018 Male Branch Tee 1
3 18-133 Barb Fitting 1 /
2
NPT x 3 /
4
HB 1
4 23-184 Male Connector 1
5 13-584 Oil Tank 1
6 13-699 Filler Breather 1
HMS-8-32-050 Machine Screw #8-32 x 1 /
2
6
HWS-8 Star Washer #8 6
7 HB-14-20-075 Bolt 1 /
4
- 20 x 3 /
4
4
HW-14 Washer 1 /
4
4
HWL-14 Lockwasher 1 /
4
4
8 34-028 Oil Tank Bracket 1
9 18-118 1 /
8
Pipe Plug 1
10 18-009 Straight Elbow 1
