EXPLANATION OF SYMBOLS
Direct Current
41-36127-0001 Rev. 3
OUTPUTS: Output common should be connected to Protective Earth in the end application. The output is
intended for Protectively Earthed Signal Output and Intermediate Circuits only. The output is not acceptable for
patient connection without additional isolation. The DC output is SELV under normal and single fault
conditions.
OVERVOLTAGE PROTECTION: The output is monitored for an overvoltage condition. In some
applications where an overvoltage condition could result in a hazard as defined in applicable safety standards,
redundant or additional overvoltage protection may be required. Consult factory for details.
CAUTION: When performing Dielectric Strength Tests, catastrophic failure of the unit may result if a
Dielectric Strength test voltage greater than 1800 V ac is applied between primary and secondary circuits. The
components providing isolation from primary to secondary cannot be tested while installed in the power supply
without overstressing basic (primary to ground) insulation. All isolating components are individually 100 %
tested at 4800 V ac prior to installation.
ISOLATION: The creepage distance between primary and ground is 4 mm minimum; between primary and
secondary circuits is 8 mm minimum. Secondary to ground creepage is not defined or controlled. The output
common is bypassed to ground using a 1000 pF 400V Y2 Type capacitor. The required creepage and clearance
distances from primary circuits to ground and secondary circuits must be maintained after installation to preserve
the intended safety.
TEMPERATURES: The maximum operating temperatures of certain safety components, as defined in the
applicable safety standards, must not be exceeded after installation to preserve the intended safety. The output
power, ambient air temperature and the availability, amount, direction and/or restriction of airflow influence the
temperatures of these components.
OVERCURRENT PROTECTION: The MINT1065A series has dual internal fusing as required by IEC/EN/UL
60601-1.
WARNING! RISK OF FIRE! A blown internal fuse is an indication of catastrophic failure of circuit
component(s). Refer to fuse marking on the supply for rating. Repair must be performed by SLPE authorized
personnel.
WARNING! SHOCK HAZARD! Dangerous voltages are present on some components, printed wiring traces
and heatsinks.
C O N N E C T I O N S
SLPE will not be liable for the safety, reliability or performance of these power supplies if a) any changes, modifications or repairs are carried out by other
than authorized agents of SLPE, or b) the installation of the supply is not in accordance with these installation instructions and the applicable UL, CSA, and
EN/IEC safety standards
.
41-36127-0001 Rev. 3 Page 2 of 2
J1 Pin AC Input J2 Pin DC Output
1 Line 1 Output #1 (+)
3 Neutral 2 Output #1 (+)
3 Return
4 Return
RECOMMENDED MATING CONNECTORS
J1 AMP 640250-3 (center pin not used)
J2 AMP 640250-4
CAUTION
Do not exceed 5 Amps per contact
