s
peCifiCaTions
Electrical Requirements
The chart below shows the recommended electrical specifications for each kiln model. If you are uncertain about your
existing power, have it checked by an electrician. If you are installing a new kiln, have the electrician follow this guide.
Electrical requirements for Skutt Automatic Kilns
Wire Breaker Max NEMA
Voltage Amp Watts Size* Size Temp Receptacle
GP706 115 15 1690 12 20 1650 5-15
GM10F 115 15 1725 12 20 1800 5-15
GM814 240 27.8 6660 8 40 1800 6-50
GM814 208 32 6656 8 40 1800 6-50
GM1014 240 34 8140 6 50 1800 6-50
GM1014 208 39.1 8140 6 50 1800 6-50
GM1414 240 34.7 8320 6 50 1800 6-50
GM1414 208 40 8320 6 50 1800 6-50
GM1414 3ph 240 20 8320 10 30 1800 15-50
GM1414 3ph 208 23.1 8320 10 30 1800 15-50
GM818 240 27.8 6660 8 40 1800 6-50
GM818 208 26.7 5550 8 40 1800 6-50
GM1018 240 39.4 9460 6 50 1800 6-50
GM1018 208 40 8320 6 50 1800 6-50
GM1027 240 48 11520 6 60 1800 6-50
GM1027 208 48 9980 6 60 1800 6-50
GM1027 3ph 240 29.3 11520 8 40 1800 15-50
GM1027 3ph 208 31.7 11000 8 40 1800 15-50
GM1227 240 48 11520 6 60 1800 6-50
GM1227 208 48 9980 6 60 1800 6-50
GM1227 3ph 240 29.3 11520 8 40 1800 15-50
GM1227 3ph 208 31.7 11000 8 40 1800 15-50
GM22CS 240 31 7450 8 40 1800 6-50
GM22CS 208 35.8 7450 6 50 1800 6-50
GM22CS 3ph 240 17.9 7450 10 30 1800 15-50
GM22CS 3ph 208 20.7 7450 10 30 1800 15-50
All Skutt kilns are equipped with a type K thermocouple.
*For each additional 50 feet use heavier wire, numerically two numbers lower—for example, instead of #10, use
#8. If you anticipate installing any larger kiln in the future, use the heavier wire.
